An ideal introduction to Ortofon moving-coil sound, with an elliptical diamond, open dynamics and a touch of warmth. A versatile cartridge offering excellent value. Read more.
The Ortofon MC Quintet Red is an excellent introduction to the refined performance of a moving-coil cartridge. Its elliptical diamond traces the record groove accurately, producing an open, dynamic and musical sound with a pleasantly warm character. With its well-balanced performance and excellent price-to-performance ratio, this versatile MC cartridge is an attractive choice for music lovers looking to unlock more of their turntable’s potential.
Explore all Ortofon products or compare this model with our other MM and MC turntable cartridges.
| Cartridge type | Moving Coil (MC) |
| Output voltage | 0.5 mV at 1 kHz, 5 cm/sec |
| Channel balance | < 1.5 dB at 1 kHz |
| Channel separation | > 21 dB at 1 kHz |
| Frequency response | 20 Hz - 20 kHz, ± 2.5 dB |
| Tracking ability | 65 µm at 315 Hz |
| Dynamic lateral compliance | 15 µm/mN |
| Stylus type | Elliptical |
| Stylus tip radius | r/R 8/18 µm |
| Tracking force range | 2.1 - 2.5 g |
| Recommended tracking force | 2.3 g |
| Tracking angle | 20° |
| Internal impedance | 7 ohms |
| Recommended load impedance | Above 20 ohms |
| Body material | PC thermoplastic |
| Colour | Red |
| Mounting | Half-inch top mount |
| Weight | 9 g |
The MC Quintet Red requires a phono preamplifier or amplifier input designed for low-output moving-coil cartridges. Set the tracking force to 2.3 grams and use a load impedance above 20 ohms. Accurate cartridge alignment is essential for optimal tracking and minimum record wear. For turntables with a detachable headshell, the Ortofon LH-4000 headshell is a suitable partner for the MC Quintet series.
