WiiM Bar 3.0.2 soundbar with Dolby Atmos, DTS, 2.1-inch touchscreen, 135W, HDMI eARC, Wi-Fi 6E, RoomFit and wireless expansion to a 5.1.2 home cinema system. Read more.
The WiiM Bar is a powerful 3.0.2-channel soundbar for movies, television, gaming and high-quality music streaming. Dolby Atmos, DTS:X, two upward-firing height channels and 135W of total system power create a broad and spacious presentation from a single elegant enclosure.
Its circular 2.1-inch colour touchscreen displays album artwork, playback information, sources, EQ settings, Smart Presets, clock faces and audio visualisations. The WiiM Bar therefore combines convincing home-cinema sound with the extensive streaming and multiroom capabilities of the WiiM ecosystem.
The 3.0.2 configuration consists of three forward-facing audio channels and two upward-firing height channels. The dedicated centre reproduction keeps dialogue clearly positioned in the middle of the screen. The top-firing drivers reflect sound from the ceiling to add height and space to compatible movies, series and games.
Through HDMI eARC, the WiiM Bar supports LPCM, Dolby Atmos, Dolby TrueHD, Dolby Digital Plus, AC3, DTS and DTS:X. This allows it to process modern multichannel audio signals from a compatible television, media player, games console or streaming service.
The slim enclosure contains eight active drivers. At the front are three 110 × 52 mm mid-woofers and three 52 × 52 mm tweeters. Two 52 × 52 mm full-range drivers fire upwards to reproduce height effects. Four 115 × 50 mm passive radiators reinforce low-frequency performance.
This acoustic system is designed to provide a wide soundstage, clear dialogue, detailed effects and a stronger low-frequency foundation than is normally expected from a compact all-in-one soundbar. Total system power is 135W.
The circular colour touchscreen is the visual centrepiece of the WiiM Bar. It can display album artwork, track information, the active source, volume, EQ settings, Smart Presets, recently played music, clock faces and audio visualisations.
The display also provides direct access to playback, volume, source selection, presets and EQ settings. Many everyday functions can therefore be controlled without reaching for a smartphone or remote control.
RoomFit uses the WiiM Home app and the microphones of a compatible smartphone to analyse how the room and placement affect the sound. It then adjusts the frequency response to reduce unwanted peaks and dips.
Clear Voice and AI Dialog Enhancement help bring speech forward during busy scenes. Night Mode reduces large changes in volume, making films and television easier to follow at lower listening levels. Dedicated settings for movies, music and voices are also available.
HDMI eARC is the recommended connection for a modern television. It allows the TV to send multichannel audio to the WiiM Bar, while volume can normally be controlled with the television remote. An optical digital input is available for televisions without ARC or eARC.
Additional connectivity includes line-in, USB Audio In/Out, USB Host, Ethernet, tri-band Wi-Fi 6E and Bluetooth 5.4. The soundbar does not have a separate HDMI video input. External video sources should therefore be connected directly to the television, which sends their audio to the soundbar through HDMI eARC.
Explore our selection of high-quality HDMI cables when an additional or longer cable is required.
The WiiM Bar is designed for more than television sound. The WiiM Home app provides access to music services, internet radio, local media libraries and extensive controls for streaming and multiroom playback.
Direct streaming options include Spotify Connect, TIDAL Connect, Qobuz Connect, Google Cast Audio, Amazon Music Cast, DLNA/UPnP, Qplay 3.0, Logitech Media Server and Roon. Wi-Fi 6E, Ethernet and Bluetooth 5.4 allow flexible integration into a modern home network.
The WiiM Bar works independently as a complete 3.0.2 soundbar, but it can be expanded wirelessly at a later stage. Two WiiM Sound or WiiM Sound Lite speakers can be used as left and right surround channels.
Adding the wireless WiiM Sub Pro creates a complete 5.1.2 configuration. The system can also be built in stages: the Sub Pro alone creates 3.1.2, while two surround speakers without a subwoofer create a 5.0.2 system.
The WiiM Bar can be controlled through its touchscreen, the WiiM Home app and the included rechargeable WiiM Bar Remote. The remote includes controls for volume, playback, source selection and presets, together with push-to-talk Alexa operation.
Voice control is also possible through an external Alexa or Google Home device. This provides a choice between direct touchscreen control, the app, the remote control and voice commands.
| Brand | WiiM |
| Model | Bar |
| Product type | Active Dolby Atmos soundbar |
| Channel configuration | 3.0.2, wirelessly expandable to 3.1.2, 5.0.2 or 5.1.2 |
| System power | 135W total |
| Front mid-woofers | 3 × 110 × 52 mm |
| Front tweeters | 3 × 52 × 52 mm |
| Height channels | 2 × 52 × 52 mm top-firing full-range drivers |
| Passive radiators | 4 × 115 × 50 mm, front and rear |
| Supported audio formats | LPCM, Dolby Atmos, Dolby TrueHD, Dolby Digital Plus, AC3, DTS and DTS:X |
| TV connection | HDMI eARC with HDMI-CEC |
| Additional connections | Optical, line-in, USB Audio In/Out and USB Host |
| Network | Tri-band Wi-Fi 6E and Ethernet |
| Bluetooth | Bluetooth 5.4 |
| Display | Circular 2.1-inch full-colour LCD touchscreen |
| Room correction | RoomFit automatic calibration |
| Listening functions | Clear Voice, AI Dialog Enhancement, Night Mode, Movie Mode, Music Mode and Voice Mode |
| Streaming | Spotify Connect, TIDAL Connect, Qobuz Connect, Google Cast Audio, Amazon Music Cast, DLNA/UPnP, Qplay 3.0, LMS and Roon |
| Control | Touchscreen, WiiM Home app, WiiM Bar Remote and external Alexa or Google Home devices |
| Wall mounting | Yes, wall brackets included |
| Dimensions | 1060 × 105 × 74 mm |
| Height without foot | 70 mm |
| Weight | 5 kg |
| Power input | 100–240V AC, 50/60Hz |
| Colour | Black |
The first 3 represents the three forward-facing audio channels. The 0 means that a separate subwoofer is not included as standard. The final 2 represents the two upward-firing height channels used for Dolby Atmos effects.
Yes. The WiiM Bar has four built-in passive radiators and works independently as a complete 3.0.2 soundbar. The WiiM Sub Pro can be added later for deeper and more powerful low-frequency reproduction.
A complete 5.1.2 configuration consists of one WiiM Bar, one WiiM Sub Pro and two WiiM Sound or WiiM Sound Lite speakers operating as wireless surround channels.
HDMI eARC is the recommended connection. The optical digital input can be used with a television without ARC or eARC. Make sure HDMI-CEC and the ARC or eARC output are enabled in the TV settings.
No. The WiiM Bar uses one HDMI eARC connection for the television's audio signal. Blu-ray players, games consoles and other video sources should be connected directly to the television.
WiiM does not currently list AirPlay 2 among the officially supported streaming protocols for the WiiM Bar. Available alternatives include Google Cast Audio, Spotify Connect, TIDAL Connect, Qobuz Connect, Bluetooth, Roon and the WiiM Home app.
Yes. The required wall brackets are included. Leave sufficient free space above the soundbar so that the upward-firing Dolby Atmos drivers can operate effectively.
Explore the complete range of WiiM products or compare the WiiM Bar with other solutions in our soundbar category.
